MZKP-N1 BAMBOO EXPANDING AND STRANDING MACHINE

It is a new kind of machine for strand woven furniture boards raw material making. It is applicated in strand woven bamboo industry.

Feeding the 1/4, 1/3, 1/2 raw bamboo into this machine and you get

fully stranded bamboo strips.

Milling Blade Size: 90*180mm

Blade Equipped: 4 PCS

Iron Teeth Feeding Roller Spec.

120*45mm (4 pcs)

Feeding Speed:30 to 40M per Min

Main Axis Rotation Speed: 3500 R/MIN

Processing thickness: 3 to 14MM

Processing width

(The materials expanding width):

No wider than 170 MM.

Stranded Width

(finished products after stranding) :

No wider than 240MM

Minimum Processing Length: 450 MM

Machine Size:5800*900*1500MM

Weight: 4900KGS
